GT-1001M™

Description[±]

The GAD GT-1001M™ is a two-way, bass reflex, multi-angle loudspeaker system featuring flat frequency response, low distortion and wide dynamic range. Designed for permanent and semi-permanent applications.

This model comes standard with a pole mount adapter suited for 1.38" speaker poles, making it suitable for main PA and floor monitor applications.

The GT-1001M™ is designed for near field applications where a smooth, dynamic range is needed. The GT-1001M™ is an ideal choice for either analog or digital reproductions where clean, clear response is a must. The GT-1001M™ boasts wide-range dispersion for portable A/V events or even for side-fill or delay monitoring applications.

Specifications[±]

Power Handling :
(RMS):	250 Watts
(Program):	500 Watts
(Peak to Peak):	1000 Watts

Frequency Response:	60 Hz - 18.5 kHz

Sensitivity (1W @ 1M):	99 dB SPL

Nominal Impedance:	8 ohms

Dispersion:	Horizontal 90°
	Vertical 90°

Components:
Low Frequency Driver	10" Cone
Magnet Material	Ferrite
Cone Material	Weather-Treated paper


Components:
High Frequency Driver	1" Compression Driver
Horn Material	13-Ply Birch

Crossover Type:	Passive

Crossover Frequency:	2.2 kHz

Enclosure Type:	Multi-Angle

Enclosure Material:	13-ply Baltic Birch

Enclosure Construction:	Dado and Rabbet Joinery

Enclosure Finish:	Textured Black

Grille:	Powder-Coated, Perforated Steel

Connectors:	Two NL4 Speakon®

Product Dimensions:
(inches)	H - 12.63" W - 18.75" D - 11.75"
(millimeters)	H - 320.80 W - 476.25 D - 298.45

Product Weight:	28.0 Lbs / 12.6 Kgs

Shipping Dimensions:
(inches)	H -22.38" W -16.75" D -16.00"
(millimeters)	H -568.45 W -425.45 D -406.40

Shipping Weight:	32.0 Lbs / 14.4 Kgs

Available Finish Configurations [±]

	GT-1001M-HP
	With handles and pole mount

Compatible Accessories
78-023 Mount Metal External Adaptor for 1.38" (35mm) Poles
